High Brightness LCD Battery Charger Discharger Single Real Time Data Memory

Name: High Brightness LCD Battery Charger Discharger Single Real Time Data Memory
Brand: Huaying
Price: 1 USD

China High Brightness LCD Battery Charger Discharger Single Real Time Data Memory wholesale

Brand Name : Huaying

Model Number : HYBT-701

Certification : ISO

Place of Origin : Wuhan Hubei China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T L/C

Supply Ability : 200 sets per month

Delivery Time : 7 Working Days

Packaging Details : Wooden Case

Application : battery activation,check discharge,charge

Data display : charge current/battery charged capacity/battery voltage/charge time and etc

Large data memory : Save 10 groups of activation data,10 groups of check discharge test data,10 groups of charge test data

Communication : RS232 port and USB

Carry method : Portable type ,move with roller wheel

Display mode : LCD with High-brightness

Contact Now

High Brightness LCD Battery Charger Discharger Single Real Time Data Memory

Introduction

It is a compact unit for daily maintenance of single cell, especially for old cells. It plays three roles: charger, discharger and activator, which will facilitate your maintenance for batteries. These three functions could be used individually or comprehensively.

Features

1/. Portable device

2/. User friendly

3/. Well designed and easy-to-do

4/. Powerful functions with 3 in 1 (discharger, charger and activator)

5/. Accurate data results and vivid waveforms

6/. Integrated functions for displaying, controlling and loading

7/. Password management in key parts

8/. Safety circuits to prevent damage to cells

9/. Longtime monitoring of cell condition

10/. Direct USB drive for data transferring

11/. Convenient analysis software in PC

12/. Software system updatable

Technical index

Measurement type of cell voltage	2V/6V/12V;
Measurement range of cell voltage	2V:0～3V; 6V: 4-8V; 12V:4-15V
Resolution of cell voltage	2V: 0.001V,6V: 0.01V, 12V:0.01V
Voltage testing accuracy	0.5%
Working range of charge and discharge current	2A～100A
Control accuracy of charge and discharge current	0.1A
Current testing accuracy	1%
Battery capacity check range	2V:20-1000Ah; 6V:20-200Ah:12V:20-300Ah;
Working voltage	AC 220±15%
Communication mode	RS232 communication and USB communication
Cooling mode	Refrigeration by blasting
Working environment	Temperature: 0℃～40℃ Humidity: 20%～80%RH
Storage condition	-20℃～70℃ package and storage
Display mode	LCD with High-brightness
External dimensions(w×h×l)	450mm×190mm×585mm
Weight	11kg
Carry method	Portable type ,move with roller wheel

High Brightness LCD Battery Charger Discharger Single Real Time Data Memory

Product Tags:

battery capacity tester

battery impedance tester

High Brightness LCD Battery Charger Discharger Single Real Time Data Memory Images
